Main configurations:

• Working area: 1300*2500*300mm;

• 8/10 PCS tool changer;

• Heavy machine structure;

• Separately control box, Anti-interference and easy to connect;

• 9.0kw HQD automatic tool changer spindle, Italy HSD brand for optional;

• All the axis adopted Taiwan HIWIN 30 square linear guide rails;

• XY axis choose high precision helical gear rack, TBI double nut ball screw for Z aixs;

• Big power Japan Yaskawa servo motor and driver, Delta servo for optional;

• Taiwan Syntec control system;

• Double vacuum working table with big power vacuum pump;

• Double bags dust collector;

• Automatic Oil lubrication system;

• France Schneider safety switch;

Application field:

• Furniture industry: cabinet doors, wooden doors, solid wood, panel, door and window furniture.

• Decoration industry: screen, wave board, large wall hanging, advertising board making.

• Arts and crafts industry: it can engrave exquisite words and patterns on the manmade stone, wood, bamboo, marble, organic board, double color board;

• Construction industry: ACP(Aluminum Composite Panels), Alubond;

Description&Specifications:

Number	Description	Parameter
1	XYZ working area	1300*2500*300mm
2	Table size	1310*3000mm
3	XYZ travel positioning accuracy	±0.01mm
4	XYZ repositioning positioning accury	±0.01mm
5	Gantry	Steel
6	Transmission system X-Y axis	High precision helical gear rack
7	Transmission system Z axis	Double nut Ball screw
8	Spindle power	9.0KW HQD
9	Cooling method	Air cooling
10	Spindle speed	0-24000rmp
11	Max velocity	80m/min
12	Max working speed	50m/min
13	Work mode	Japan yaskawa servo motor
14	Driver	Japan yaskawa driver
15	Working voltage	AC380V 3 phase
16	Command language	G code
17	Interface	USB  or parallel port
18	Operating system	Syntec
19	X-Y resolution	<0.025mm
20	Software environment	Artcam
21	Running environment	Temperature:0-45℃
22	Packing size	3500*2200*2200mm
